Skep 117 Swivel-Arm Bike Rack

Swivel Arm for Bike Racks

• Dimensions: 107 x 30.7 x 19.5 cm
• Weight: 27.5 kg

• Compatible withall trailer hitches (gooseneck, detachable ball, retractable trailer hitch included): SUVs, 4x4s, pickups, vans, delivery vans, etc.

• Select whether the door opens tothe right (passenger side) or to the left (driver's side)

• Payload up to80 kg(including bicycles and bike racks)

• Installation and removal take 5 minutes, allowing you to quickly tow a trailer after removing the swivel arm

• Approved throughout Europe

• Swivels117°, providing full access to the rear of the vehicle (tailgate or double doors)

• Suitable for transporting bicycles, a box, or skis

• European patent application filed.

Compatibility

To install an SKEP 117 on your vehicle, please note the following requirements :

1. Tow Hitch: Your vehicle must be equipped with a standard, compatible tow hitch.
2. Minimum clearance: There must be a clearance ofat least 4 cm betweenthe lower edge of the tailgate or double doors and your trailer hitch in order to install the SKEP 117.
3. Maximum Load: The permissible vertical load (or "S" load) must be compatible with the total weight of the SKEP 117, the bike rack, and the bikes being transported. The "S" load rating of the trailer hitch (indicated on a riveted plate attached to the hitch) must be taken into account to ensure that this limit is not exceeded.
4. Weight of the bike rack: approximately15 kg fora bike rack mounted on the trailer hitch, which is factored into the calculation along with the weight of the bikes and the weight of the SKEP 117.

By adhering to these criteria, you ensure a safe and compliant installation on the vehicle.

Minimum clearance: There must be a clearance of at least 4 cm between the lower edge of the tailgate or double doors and your trailer hitch in order to install the SKEP 117.
